Distributed Power Station

Distributed power station is a kind of photovoltaic power station which developed by using the roof resource of the factory, public building, residential building, etc. The size of this type of power station is limited by effective roof area. The installed capacity is generally between several kilowatts and tens megawatts. The power generation encourages local consumption, directly import into the low voltage distribution network or middle & high voltage power network which is 35kV and below. The direction of the component, the angle of inclination and the condition of the shadow are various. This kind of station is the main form of distributed photovoltaic applications, mainly concentrated in the eastern and southern areas of our country.

1) Industrial roof



Outline
■ 380V or 10kV connected to the public grid or user grid;
■ The roof is not flat, the direction is different;
■ Power station capacity is generally more than 300kW.



Features Advantages
1 Security: DC side with special lightning protection, safe and reliable;
2 Friendly: integrated access system, convenient for power station access to network;
3 Flexibility: efficient string inverters, multi-channel MPPT, suitable for complex applications;
4 Efficient: "one-stop" solution system which shorten the construction and save cost.

Program components:

01 / PV inverters

SUN2000-33KTL

Intelligent: intelligent monitoring and fault detection by 6 sets of string inverters, can reduce 80% of the fault location time;
Efficient: maximum efficiency 98.7% European efficiency 98.4%, Photon test efficiency double A+, power generation upgrade more than 5%;
Secure: Built-in type II AC and DC lightning protection module, no fuse design, so that prevent fire hazards caused by DC-side fault effectively;
Reliable: natural cooling, no need for external fan, free from fan replacement and maintenance.


02 / AC distribution box

ST-PD-30
(1) Double stage bus of photovoltaic cell board
(2) The power off operation of disconnect point is clearly visible when providing maintenance
(3) Provide inverter AC and DC side lightning protection
(4) Short circuit, grounding and over current protection
(5) Simple operation, easy maintenance
(6) Selection of domestic high-quality electrical devices to improve the reliability and safety of the system
(7) Can be customized according to customer demand


03 / Monitoring System

• Meet the demand of unattended monitoring requirements, 7*24 hours stable operation, the abnormal fault automatic alert through messages and e-mails;
• Grid-friendly, real-time data transmission and seamless connection with power grid, electricity and power information are clear-cut;
• Based on a large life data analysis, improve the operational efficiency of power station, provide guidance for operation, maintenance and repair;
• Friendly interface, smooth operation, integrate power monitoring, operation and management in one, providing a better use experience.

04 / PV bracket



2) Commercial roof



Outline
■ 380V voltage access to the public power grid or user grid;
■ Common in the commercial building roof which is not flat and toward inconsistently;
■ Power station capacity is generally more than 200kW.

Features Advantages
1 Security: DC side with special lightning protection, safe and reliable;
2 Friendly: integrated access system, convenient for power station access to network;
3 Flexibility: efficient string inverters, multi-channel MPPT, suitable for complex applications;
4 Efficient: "one-stop" solution system which shorten the construction and save cost.

Program components:

01 / PV inverters

SUN2000-33KTL

Intelligent: intelligent monitoring and fault detection by 6 sets of string inverters, can reduce 80% of the fault location time;
Efficient: maximum efficiency 98.7% European efficiency 98.4%, Photon test efficiency double A+, power generation upgrade more than 5%;
Secure: Built-in type II AC and DC lightning protection module, no fuse design, so that prevent fire hazards caused by DC-side fault effectively;
Reliable: natural cooling, no need for external fan, free from fan replacement and maintenance.




02 / AC distribution box

ST-PD-30
(1) Double stage bus of photovoltaic cell board
(2) The power off operation of disconnect point is clearly visible when providing maintenance
(3) Provide inverter AC and DC side lightning protection
(4) Short circuit, grounding and over current protection
(5) Simple operation, easy maintenance
(6) Selection of domestic high-quality electrical devices to improve the reliability and safety of the system
(7) Can be customized according to customer demand

03 / Monitoring System

Shinetech Solar Monitoring System

• Meet the demand of unattended monitoring requirements, 7*24 hours stable operation, the abnormal fault automatic alert through messages and e-mails;
• Grid-friendly, real-time data transmission and seamless connection with power grid, electricity and power information are clear-cut;
• Based on a large life data analysis, improve the operational efficiency of power station, provide guidance for operation, maintenance and repair;
• Friendly interface, smooth operation, integrate power monitoring, operation and management in one, providing a better use experience.

04 / PV bracket




3) Public building roof




Outline
■ 380V or 10kV connected to the public grid or user grid;
■ Common in the commercial building roof which is not flat and toward inconsistently;
■ Power station capacity is generally above 10kW-200kw.



Features Advantages
1 Security: DC side with special lightning protection, safe and reliable;
2 Friendly: integrated access system, convenient for power station access to network;
3 Flexibility: efficient string inverters, multi-channel MPPT, suitable for complex applications;
4 Efficient: "one-stop" solution system which shorten the construction periodshorten and save cost.

Program components:

01 / PV inverters

SUN2000-33KTL

Intelligent: intelligent monitoring and fault detection by 6 sets of string inverters, can reduce 80% of the fault location time;
Efficient: maximum efficiency 98.7% European efficiency 98.4%, Photon test efficiency double A+, power generation upgrade more than 5%;
Secure: Built-in type II AC and DC lightning protection module, no fuse design, so that prevent fire hazards caused by DC-side fault effectively;
Reliable: natural cooling, no need for external fan, free from fan replacement and maintenance.


02 / Monitoring System



 • Abundant data access outlet;
 • Support for Android, iPhone, iPad;
 • Unattended operation, a powerful assistant for your power station management;
 • All-weather 24 hours uninterrupted monitoring;
 • Friendly interface, the access and use of the power station are simple;
 • You can know the operation of the power station everytime and everywhere.
